Dimensions and Specifications
Expanded Wall Thickness
0.059 in
Inner Diameter After Shrink (Imperial)
15.43 in
Inner Diameter After Shrink (Metric)
39.18 cm²
Inner Diameter Before Shrink (Imperial)
24.14 in
Inner Diameter Before Shrink (Metric)
61.32 cm²
Maximum Operating Temperature (Celsius)
110 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Operating Temperature (Celsius)
-55 °C to 110 °C
Operating Temperature Range (Celsius)
-55 °C to 110 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Outside Diameter (Bar Circumference)
15.43 - 24.14 inch
Overall Length (Imperial)
20 ft
Overall Length (Metric)
6.1 m
Recovered Wall Thickness
0.138 in
Rectangular Size
(8 X 1/4) to (10 x 3/4) Inch (for 5 kV, 8 kV, 15 kV, 25 kV)
Round Size (Diameter)
See Sizing Chart on Data Sheet
Square Size
(5 x 5) Inch (for 25 kV)
Voltage
5 kV
Operating Temperature Celsius
-55 °C to 110 °C
Overall Length Imperial
20.0
Width
12.64 in
32.1 cm
Height
17.64 in
44.8 cm
Length
12.72 in
32.3 cm
Volume
46.45 dm3
Weight
21.2 lb
9.62 kg
