Dimensions and Specifications
Approximate Length
15
Cable Diameter Range
8,1 - 39,4 mm
Cable Length (Imperial)
15 in
Cable Length (Metric)
381 mm
Cable Tie Base Height
15 in
Cable Tie Length
381 mm
Maximum Bundle Diameter
4 Inch
Maximum Bundle Diameter (Metric)
102 mm
Maximum Insulation Outer Diameter (Metric)
3.7 mm
Maximum Insulation Outside Diameter
0.145 in
Maximum Operating Temperature
85 Degree Celsius
Maximum Operating Temperature (Celsius)
85 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
185 Degree Fahrenheit
Maximum Recommended Voltage Rating
600 V
Minimum Bundle Diameter
0.1875 Inch
Minimum Bundle Diameter (Metric)
4.8 mm
Minimum Installation Temperature (Celsius)
-20 Degree Celsius
Minimum Installation Temperature (Fahrenheit)
-4 Degree Fahrenheit
Minimum Operating Temperature (Celsius)
-40 Degree Celsius
Minimum Operating Temperature (Fahrenheit)
-40 Degree Fahrenheit
Operating Temperature (Celsius)
85 Degree Celsius
Operating Temperature (Fahrenheit)
185 Degree Fahrenheit
Operating Temperature Range (Celsius)
-40 °C to 85 °C
Operating Temperature Range (Fahrenheit)
-40 °F to 185 °F
Overall Length (Imperial)
15 in
Overall Length (Metric)
381 mm
Overall Width (Imperial)
0.298 in
Overall Width (Metric)
7.6 mm
Recovered Inner Diameter (Metric)
4.75 mm
Tensile Strength (Imperial)
120 lbs
Tensile Strength (Metric)
54.43 kg
Maximum Insulation Outer Diameter Metric
3.7
Operating Temperature Celsius
85 Degree Celsius
